Carestream DryView 5700 Laser Imager


Request a Quote

Download Brochure

SKU: Carestream DryView 5700 Laser Imager Categories: , Tags: , , , , ,


The DryView 5700 Laser Imager offers simplicity and affordability for healthcare facilities of all sizes. This innovative tabletop medical imaging system offers a modest acquisition price, which is half of the affordability equation. It also delivers consistently low operating costs. This combination creates a complete picture of true affordability. It’s ideal for computed radiography (CR), digital radiography (DR), computed tomography (CT), PACS Viewer, and magnetic resonance (MR) applications.


Laser image quality
Every image on every film size is printed using true laser technology. Automatic Image Quality Control (AIQC) uses a built-in densitometer to maintain film-to-film consistency.

Broad printing capabilities
Print from CR, DR, CT, MR, PACS Viewers and other grayscale medical film applications.

CR & DR compatibility
Fully compatible with the CARESTREAM CR and DR Systems, the DRYVIEW 5700 Laser Imager is ideal for dispersed or remote printing applications from computed radiography or digital radiography systems.

Ease of operation
No daily or weekly preventive maintenance is required on print heads or film transport rollers to optimize image quality. A simplified user interface, room light film loading, and easy film loading further facilitate use.


Photothermographic (dry laser)

DryView Laser Imager Quality
True laser technology
325 pixels per inch; 78 micron laser spot spacing

Up to 45 – 85 films per hour (film size dependent)
Smaller film sizes print faster

DRYVIEW Laser imaging Film
Blue or clear 7-mil polyester base
Daylight-load film cartridges
125 sheets/cartridge
Lifetime (100+ years) film archivability addresses demanding requirements (oncology, pediatrics, etc.)

Choice of Film Sizes
14 x 17 in. (35 x 43 cm)
11 x 14 in. (28 x 35 cm)
10 x 12 in. (25 x 30 cm)
8 x 10 in. (20 x 25 cm)

Network Connectivity
Integrated DICOM interface supports printing from DICOM print modalities
Connect non-DICOM modalities using PACS Link Medical Image Managers

Network connection
10/100/1000 BaseT Ethernet connection to imager (supports jumbo frame)

Height: 19 in. (47 cm)
Width: 24 in. (61 cm)
Depth: 26 in. (66 cm)
Weight: 120 lb. (54 kg)

180–264 VAC; 50/60 Hz; maximum 4.5 amps

Operating Environment
Temperature: 59 to 91°F (15 to 33°C)
Humidity: 20 to 80% RH, non-condensing
Magnetic field: < 50 Gauss
Altitude: –100 to 10,000 ft (–30.5 to 3,048m)

Additional information

Weight 15.00 lbs
Dimensions 36 × 24 × 1 in
